GRANNING 6252 Natural Rubber Air Bag Suspension Spring/ 1R10-036 Air Ride Suspension System Spare Parts W01-358-9049

Name: GRANNING 6252 Natural Rubber Air Bag Suspension Spring 1R10036 Air Ride Suspension System Spare Parts W013589049
Brand: VKNTECH
Price: 1.00 USD

Place of Origin : Guangdong, China

Brand Name : VKNTECH

Certification : IATF16949/ISO9000

Packaging Details : CARTON/PALLET

Supply Ability : 2000000pcs/Year

MOQ : 20 Pieces

Price : $1.00 - $50.00/Pieces

Model Number : 1K9049

OE NO. : W01-358-9049

Car Model : For bus/truck&trailer

Package : Standard packing or customized

Suspension system : Air Spring Suspension

Warranty : 12 Months

Type : by sea / by air / by truck

Price condition : FOB China

Sample : Available

Brand : VKNTECH or customized

Material : Imported Natrul Rubber

Operation : Gas-filled

Service offered : OEM

Type of Goods : Air Spring/Air bags/Air Ballons

Payment term : T/T&L/C

Port : Guangzhou

Contact Now

AIRSTROKE ACTUATOR
Maximum Diameter @ 100 PSIG (inches)	11.1
Maximum Height (inches)	16
Maximum Stroke (inches)	10
Minimum Usable Height (inches)	6
Force @ 80PSI at Stroke of 1 Inch (pounds)	5070
Force @ 80PSI at Stroke of 3 Inch (pounds)	4420
Force @ 80PSI at Stroke of Maximum Stroke (pounds)	2830
Material	2-Ply Standard Cord

END CLOSURE DETAILS
Bead plate Type	3
Blind Nut Centers (inches)	6.2
Port Offset from Blind Nut Centerline (inches)	2.88

AIRMOUNT ISOLATOR
Design Height	12
Load (at Design Height) at: 40 psig (pounds)	2040
Load (at Design Height) at: 60 psig (pounds)	3140
Load (at Design Height) at: 80 psig (pounds)	4220
Natural Frequency (@80 psig) (cpm)	74
% of Isolation at Forced Frequency 400 CPM	96.5
% of Isolation at Forced Frequency 800 CPM	99.1
% of Isolation at Forced Frequency 1500 CPM	99.8

GRANNING 6252 Natural Rubber Air Bag Suspension Spring/ 1R10-036 Air Ride Suspension System Spare Parts W01-358-9049

OEM Numbers

Firestone	W01-358-9049 1T15AA-3 1T15S-6	GRANNING	6252
Goodyear	1R10-036

Prodcut Drawing

GRANNING 6252 Natural Rubber Air Bag Suspension Spring/ 1R10-036 Air Ride Suspension System Spare Parts W01-358-9049

Technical data

AIRSTROKE ACTUATOR
Maximum Diameter @ 100 PSIG (inches)	11.1
Maximum Height (inches)	16
Maximum Stroke (inches)	10
Minimum Usable Height (inches)	6
Force @ 80PSI at Stroke of 1 Inch (pounds)	5070
Force @ 80PSI at Stroke of 3 Inch (pounds)	4420
Force @ 80PSI at Stroke of Maximum Stroke (pounds)	2830
Material	2-Ply Standard Cord

END CLOSURE DETAILS
Bead plate Type	3
Blind Nut Centers (inches)	6.2
Port Offset from Blind Nut Centerline (inches)	2.88

AIRMOUNT ISOLATOR
Design Height	12
Load (at Design Height) at: 40 psig (pounds)	2040
Load (at Design Height) at: 60 psig (pounds)	3140
Load (at Design Height) at: 80 psig (pounds)	4220
Natural Frequency (@80 psig) (cpm)	74
% of Isolation at Forced Frequency 400 CPM	96.5
% of Isolation at Forced Frequency 800 CPM	99.1
% of Isolation at Forced Frequency 1500 CPM	99.8
